Console Output:
C2950 Boot Loader (C2950-HBOOT-M) Version 12.1(11r)EA1, RELEASE SOFTWARE (fc1)
Compiled Mon 22-Jul-02 17:18 by antonino
WS-C2950-24 starting...
Base ethernet MAC Address: 00:0f:23:4e:7e:c0
Xmodem file system is available.
Initializing Flash...
flashfs[0]: 3 files, 1 directories
flashfs[0]: 0 orphaned files, 0 orphaned directories
flashfs[0]: Total bytes: 7741440
flashfs[0]: Bytes used: 3725312
flashfs[0]: Bytes available: 4016128
flashfs[0]: flashfs fsck took 6 seconds.
...done initializing flash.
Boot Sector Filesystem (bs:) installed, fsid: 3
Parameter Block Filesystem (pb:) installed, fsid: 4
Loading "flash:/c2950-i6k2l2q4-mz.121-22.EA12.bin"...###########################
################################################################################
################################################################################
############################################
File "flash:/c2950-i6k2l2q4-mz.121-22.EA12.bin" uncompressed and installed, entr
y point: 0x80010000
executing...
Restricted Rights Legend
Use, duplication, or disclosure by the Government is
subject to restrictions as set forth in subparagraph
(c) of the Commercial Computer Software - Restricted
Rights clause at FAR sec. 52.227-19 and subparagraph
(c) (1) (ii) of the Rights in Technical Data and Computer
Software clause at DFARS sec. 252.227-7013.
cisco Systems, Inc.
170 West Tasman Drive
San Jose, California 95134-1706
Cisco Internetwork Operating System Software
IOS (tm) C2950 Software (C2950-I6K2L2Q4-M), Version 12.1(22)EA12, RELEASE SOFTWA
RE (fc1)
Copyright (c) 1986-2008 by cisco Systems, Inc.
Compiled Tue 08-Jul-08 00:03 by amvarma
Image text-base: 0x80010000, data-base: 0x80680000
Initializing flashfs...
flashfs[1]: 3 files, 1 directories
flashfs[1]: 0 orphaned files, 0 orphaned directories
flashfs[1]: Total bytes: 7741440
flashfs[1]: Bytes used: 3725312
flashfs[1]: Bytes available: 4016128
flashfs[1]: flashfs fsck took 7 seconds.
flashfs[1]: Initialization complete.
Done initializing flashfs.
POST: System Board Test : Passed
POST: Ethernet Controller Test : Passed
ASIC Initialization Passed
POST: FRONT-END LOOPBACK TEST : Passed
This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.
A summary of U.S. laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you require further assistance please contact us by sending email to
export@cisco.com.
cisco WS-C2950-24 (RC32300) processor (revision M0) with 19912K bytes of memory.
Processor board ID FOC0802W4N4
Last reset from system-reset
Running Standard Image
24 FastEthernet/IEEE 802.3 interface(s)
32K bytes of flash-simulated non-volatile configuration memory.
Base ethernet MAC Address: 00:0F:23:4E:7E:C0
Motherboard assembly number: 73-5781-12
Power supply part number: 34-0965-01
Motherboard serial number: FOC08030KR4
Power supply serial number: DAB08020LVE
Model revision number: M0
Motherboard revision number: B0
Model number: WS-C2950-24
System serial number: FOC0802W4N4
